！Before installation, confirm that：
This guide is for reference only; professional installation is highly recommended. By proceeding, you assume all risk. The manufacturer and seller assume no liability for any personal injury, property damage, fuel system contamination, or engine/injector failure resulting from improper installation or failure to properly prime the system before start-up.
This is the installation process for the FI-F-10-01: 2008-2010 6.4L Ford Powerstroke Diesel Fuel Filter Replaces FD4617,provided for your reference during installation.
Step 1:
The main fuel filter is located within the horizontal fuel conditioning module (HFCM) inside the driver's side frame longitudinal beams, between the fuel tank and the engine.
Step 2:
Step 3:
Step 4:
Step 5:
Remove the fuel filter from the filter cap and install a new fuel filter and fuel filter O-ring.
Step 6:
Apply a thin layer of clean engine oil to the new O-ring and then reinstall the filter/cap assembly. The torque is 25 Nm (approximately 19 ft-lbs); do not overtighten, otherwise the plastic cap may break.
Step 7:
Close the drain valve of the oil-water separator (yellow handle).
Step 8:
Use a 24 mm socket to remove the auxiliary fuel filter located on the right side of the oil filter housing. Use a syringe, suction hose, or squeegee to remove any remaining fuel from the fuel bowl.
Step 9:
Install the new O-ring onto the fuel filter cap. Lightly lubricate the seal with clean engine oil.
Step 10:
Then install the new fuel filter. The clip on top of the filter will "click" into the retaining slot on the fuel filter cap.
Step 11:
Reinstall the fuel filter into the housing; the torque is 14 Nm (approximately 125 ft-lbs).
Step 12:
Before starting the engine, turn the key to the "Run" position (as you would when starting a glow plug), pausing for 10-20 seconds at a time, repeating 3-5 times; this helps the fuel filter housing fill with fuel. After starting the engine, check for leaks.
This guide is for reference only; professional installation is highly recommended. By proceeding, you assume all risk. The manufacturer and seller assume no liability for any personal injury, property damage, fuel system contamination, or engine/injector failure resulting from improper installation or failure to properly prime the system before start-up.
This is the installation process for the FI-F-10-01: 2008-2010 6.4L Ford Powerstroke Diesel Fuel Filter Replaces FD4617,provided for your reference during installation.
The main fuel filter is located within the horizontal fuel conditioning module (HFCM) inside the driver's side frame longitudinal beams, between the fuel tank and the engine.
Step 2:
The HFCM includes the main fuel filter and a fuel-water separator. Place the container under the drain valve and open the valve 1/4 turn (yellow handle) to drain the fuel-water separator.
Step 3:
To prevent fuel spillage, we strongly recommend installing a 1/4-inch fuel line at the fuel-water separator's drain valve; this allows you to place the container on the ground without lifting it into the air. Completely drain the fuel-water separator and properly dispose of any collected fuel.
Step 4:
Use a 36mm socket wrench to remove the HFCM fuel filter.
Step 5:
Remove the fuel filter from the filter cap and install a new fuel filter and fuel filter O-ring.
Step 6:
Apply a thin layer of clean engine oil to the new O-ring and then reinstall the filter/cap assembly. The torque is 25 Nm (approximately 19 ft-lbs); do not overtighten, otherwise the plastic cap may break.
Step 7:
Close the drain valve of the oil-water separator (yellow handle).
Step 8:
Use a 24 mm socket to remove the auxiliary fuel filter located on the right side of the oil filter housing. Use a syringe, suction hose, or squeegee to remove any remaining fuel from the fuel bowl.
Step 9:
Install the new O-ring onto the fuel filter cap. Lightly lubricate the seal with clean engine oil.
Step 10:
Then install the new fuel filter. The clip on top of the filter will "click" into the retaining slot on the fuel filter cap.
Step 11:
Reinstall the fuel filter into the housing; the torque is 14 Nm (approximately 125 ft-lbs).
Step 12:
Before starting the engine, turn the key to the "Run" position (as you would when starting a glow plug), pausing for 10-20 seconds at a time, repeating 3-5 times; this helps the fuel filter housing fill with fuel. After starting the engine, check for leaks.
